NZXT H9 Flow Dual-Chamber Mid-Tower Airflow Case - Matte Black
Shop the NZXT H9 Flow Dual-Chamber Mid-Tower Airflow Case in Matte Black, featuring an uninterrupted glass panel, intuitive cable management, and space for 10 fans or three 360mm radiators. Enjoy enhanced cooling with a perforated top panel and direct GPU airflow for high-powered components. Comes with four F Series 120mm Quiet Airflow fans.
SPECIFICATIONS:
|
KEY SPECS |
|
|
Motherboard Support |
Mini-ITX, Micro-ATX, ATX |
|
Enclosure Type |
Mid-Tower |
|
Case Material |
SGCC Steel, Dark Tinted Tempered Glass |
|
DIMENSIONS |
|
|
Height |
495mm (With Feet) |
|
Width |
290mm |
|
Depth |
466mm |
|
Weight |
13.1 kg |
|
COMPATIBILITY & CLEARANCE |
|
|
CPU Cooler Clearance |
Up to 165mm |
|
GPU Clearance |
Up to 435mm |
|
PSU Clearance |
200mm |
|
Cable Management |
91mm |
|
FRONT I/O PORTS |
|
|
USB 3.2 Gen 1 Type-A |
2 |
|
USB 3.2 Gen 2 Type-C |
1 |
|
Headset Audio Jack |
1 |
|
EXPANSION SLOTS |
|
|
Standard |
7 |
|
Vertical |
0 |
|
DRIVE BAYS |
|
|
2.5" |
4 2 |
|
3.5" |
2 |
|
FAN SUPPORT |
|
|
Side |
3 x 120mm |
|
Top |
3 x 120mm / 2 x 140mm |
|
Bottom |
3 x 120mm / 2 x 140mm |
|
Rear |
1 x 120mm |
|
Filters |
All Air Intakes |
|
RADIATOR SUPPORT |
|
|
Side |
Up to 360mm |
|
Top |
Up to 360mm |
|
Bottom |
Up to 360mm |
|
Rear |
Up to 120mm |
|
FAN SPECS |
|
|
Model |
F120Q (Case Version) |
|
Speed |
1200 ± 240RPM |
|
Airflow |
62.18 CFM |
|
Static |
1.05 mm - H2O |
|
Noise |
25.1 dBA |
|
Fan Connector |
3-pin |
|
FAN SPECS |
|
|
Model |
F120RGB Duo |
|
Speed |
500 ± 1800RPM |
|
Airflow |
48.58 CFM |
|
Static |
2.42mm - H2O |
|
Noise |
29 dBA |
|
Fan Connector |
4-pin |
|
OTHERS |
|
|
Inside the Box |
H9 Elite Case 1 x Front I/O split cables 3 x 120mm RGB Duo Fan 1 x 120mm Quiet Airflow Fan (Case Version) 1 x RGB and Fan Controller Installation Accessories Manual |
