Product Details ＋

AHRI Certified Match: 214859636

Standard Features

Removable grille-style top design compliant with UL 60335-2-40
Venturi for increased velocity of airflow
Attractive Architectural Gray powder-paint finish with 500-hour salt-spray approval
Wire fan discharge grille
Steel louver coil guard
Top and side maintenance access
Single-panel access to controls with space provided for field-installed accessories
When properly anchored, meets the 2023 Florida Building Code unit integrity requirements for hurricane-type winds (Anchor bracket kits available.)

AWST Models: Equipped with a fully adjustable TXV
Direct-drive, multi-speed motors allows air volume variation for heating/cooling
Sequence-controlled, rust-resistant nickel chromium heating elements of 3, 5, 8, and 10 kW
Aluminum tubing coils on all models
Cabinet air leakage less than 2.0% at 1.0 inch H?O when tested in accordance with ASHRAE standard 193
UL 60335 2-40 Compliant
Factory installed R-32 sensor designed for the lifespan of the coil
Cabinet air leakage less than 1.4% at 0.5 inch H?O when tested in accordance with ASHRAE standard 193
Factory-installed pull-type disconnect
Thermoplastic drain pan with bottom primary and secondary drain connections
Built-in filter rack (filter included)
Large chassis (2½- and 3-ton units) front return only
Small chassis (1½- and 2-ton units) front or bottom return
Wall-hanging bracket provided
AHRI Certified; ETL Listed
